American Coach American Dream Motor Home Class A - Diesel RVs For Sale

Previous
Next
1 of 34

Experience your best life traveling in an American Dream Class A diesel motorhome by American Coach! These units are hard-working with luxurious elements under the hood and inside the cabin. They are not only powerful with a Cummins ISX turbocharged engine, but also reliable with a RoadWatch safety system!



You don't have to be a gourmet chef in order to cook a delicious meal with the two burner induction cooktop, four door refrigerator with ice maker, and quartz counters that will be easy to clean. A 15,000/20,000 towing capacity means you can bring along your favorite toys. You can even customize the interiors with three décor choices and four cabinet choices to create your dream living area!



It's time you spoiled yourself with an American Dream Class A diesel motorhome by American Coach!

  • American Dream 39RK

    American Dream 39RK Floorplan Image

    American Coach American Dream Class A diesel motorhome 39RK highlights: Rear ... more about American Dream 39RK

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 4
    Slides 4
    Length 39 ft 9 in
    Ext Width 8 ft 6 in
    Ext Height 13 ft 1 in
    Int Height 7 ft
    Interior Color Rockport, Navy Pier, Sand Creek
    Exterior Color Falling Ash, Nighthawk, South Beach, Stone Washed
    Hitch Weight 15000 lbs
    Gross Weight 47000 lbs
    Fresh Water Capacity 105 gals
    Grey Water Capacity 75 gals
    Black Water Capacity 50 gals
    Tire Size 315/80R 22.5L
    Generator 12.5KW Onan Quiet Diesel
    Fuel Type Diesel
    Engine Cummins ISL Turbocharged
    Chassis Freightliner ISL
    Horsepower 450 hp
    Fuel Capacity 150 gals
    Wheelbase 267 in
    Available Beds King
    Torque 1250 ft-lb
    Refrigerator Type Residential Four Door
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 39" x 34"
    Number of Awnings 1
    Axle Weight Front 17000 lbs
    Axle Weight Rear 20000 lbs
    Axle Weight Tag 10000 lbs
    Water Heater Type AquaHot 450D
    AC BTU 15000 btu
    Basement Storage 72 cu. ft.
    TV Info LR 50" 4K TV, BR 43" 4K LED TV, Ext. 50" LED TV
    Awning Info 18' Electric with LED Lights and Wind Sensor Retract
    Washer/Dryer Available Yes
    Gross Combined Weight 62000 lbs
    Shower Type Shower w/Seat
    Electrical Service 50 amp

    Similar Floorplans

  • American Dream 42Q

    American Dream 42Q Floorplan Image

    American Coach American Dream Class A diesel motorhome 42Q highlights: Bath and ... more about American Dream 42Q

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 6
    Slides 3
    Length 42 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 13 ft 1 in
    Int Height 7 ft
    Interior Color Rockport, Navy Pier, Sand Creek
    Exterior Color Falling Ash, Nighthawk, South Beach, Stone Washed
    Hitch Weight 15000 lbs
    Gross Weight 47000 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Tire Size 315/80R22.5
    Generator 12.5kw Onan Quiet Diesel
    Fuel Type Diesel
    Engine Cummins ISL Turbocharged
    Chassis Freightliner ISL
    Horsepower 450 hp
    Fuel Capacity 150 gals
    Wheelbase 302 in
    Available Beds King
    Torque 1250 ft-lb
    Refrigerator Type Residential Four Door
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 30" x 42"
    Number of Awnings 1
    Axle Weight Front 17000 lbs
    Axle Weight Rear 20000 lbs
    Axle Weight Tag 10000 lbs
    Water Heater Type AquaHot 450D
    AC BTU 15000 btu
    Basement Storage 131 cu. ft.
    TV Info LR 50" Pop-Up LED TV, BR 43" 4K LED TV, Ext. 50" LED TV
    Awning Info 18' Electric with LED Lights and Wind Sensor Retract
    Washer/Dryer Available Yes
    Gross Combined Weight 62000 lbs
    Shower Type Shower w/Seat
    Electrical Service 50 amp

    Similar Floorplans

  • American Dream 42V

    American Dream 42V Floorplan Image

    American Coach American Dream Class A diesel motorhome 42V highlights: Bath and ... more about American Dream 42V

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 6
    Slides 4
    Length 42 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 13 ft 1 in
    Int Height 7 ft
    Interior Color Rockport, Navy Pier, Sand Creek
    Exterior Color Falling Ash, Nighthawk, South Beach, Stone Washed
    Hitch Weight 15000 lbs
    Gross Weight 47000 lbs
    Fresh Water Capacity 100 gals
    Grey Water Capacity 60 gals
    Black Water Capacity 40 gals
    Tire Size 315/80R22.5
    Generator 12.5kw Onan Quiet Diesel
    Fuel Type Diesel
    Engine Cummins ISL Turbocharged
    Chassis Freightliner ISL
    Horsepower 450 hp
    Fuel Capacity 150 gals
    Wheelbase 302 in
    Available Beds King
    Torque 1250 ft-lb
    Refrigerator Type Residential Four Door
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 52" x 50"
    Number of Awnings 1
    Axle Weight Front 17000 lbs
    Axle Weight Rear 20000 lbs
    Axle Weight Tag 10000 lbs
    Water Heater Type AquaHot 450D
    AC BTU 15000 btu
    Basement Storage 131 cu. ft.
    TV Info LR 50" 4K Pop-Up LED TV, BR 43" 4K LED TV, Ext. 50" LED TV
    Awning Info 18' Electric with LED Lights and Wind Sensor Retract
    Washer/Dryer Available Yes
    Gross Combined Weight 62000 lbs
    Shower Type Shower w/Seat
    Electrical Service 50 amp

    Similar Floorplans

  • American Dream 45A

    American Dream 45A Floorplan Image

    American Coach American Dream Class A diesel motorhome 45A highlights: Bath and ... more about American Dream 45A

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 6
    Slides 3
    Length 44 ft 11 in
    Ext Width 8 ft 6 in
    Ext Height 13 ft 1 in
    Int Height 7 ft
    Interior Color Rockport, Navy Pier, Sand Creek
    Exterior Color Falling Ash, Nighthawk, South Beach, Stone Washed
    Hitch Weight 15000 lbs
    Gross Weight 51000 lbs
    Fresh Water Capacity 105 gals
    Grey Water Capacity 75 gals
    Black Water Capacity 50 gals
    Tire Size 315/80R22.5
    Generator 12.5kw Onan Quiet Diesel
    Fuel Type Diesel
    Engine Cummins ISX Turbocharged
    Chassis Freightliner ISX
    Horsepower 605 hp
    Fuel Capacity 150 gals
    Wheelbase 319 in
    Available Beds King
    Torque 1950 ft-lb
    Refrigerator Type Residential Four Door
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 30" x 55"
    Number of Awnings 1
    Axle Weight Front 17000 lbs
    Axle Weight Rear 20000 lbs
    Axle Weight Tag 14000 lbs
    Water Heater Type AquaHot 450D
    AC BTU 15000 btu
    Basement Storage 141 cu. ft.
    TV Info LR 50" 4K Pop-Up LED TV, BR 43" 4K LED TV, Ext. 50" LED TV
    Awning Info 18' Electric with LED Lights and Wind Sensor Retract
    Washer/Dryer Available Yes
    Gross Combined Weight 71000 lbs
    Shower Type Shower w/Seat
    Electrical Service 50 amp

    Similar Floorplans

American Dream Features:

Standard Features (2022)



Chassis

  • Freightliner ISL 450 HP (39RK, 42Q, 42V)
  • Freightliner ISL 605 HP (45A Only)
  • Front Suspension: ZF RL80EM IFS Air
  • 55 Degree Wheel Cut
  • Rear Suspension: V-Ride Air Suspension
  • Front Brakes: Bendix Air Disc w/ ABS
  • Rear Brakes: Meritor Drum w/ ABS
  • Custom-Tuned SACHS Shocks
  • Select Drive Steering
  • Roll Stability Control
  • Valid Air Leveling
  • Radiator Configuration Side
  • Remote Air Connection
  • Engine Brake: Compression Brake 3 Stage
  • Electric Alert Horn
  • Keyless Push Button Start
  • Automotive-Style Headlights
  • Front Tires, Rear Tires, Tag Tires: 315/80R 22.5L
  • Aluminum Wheels Front/Rear
  • Brake Sync
  • RoadWatch Safety System w/ Collision Mitigation, Adaptive Cruise, Electronic Stability Control, Roll Stability Control, Automatic Traction Control, and Integrated Mobileye

Engine Equipment

  • Cummins ISL Turbocharged 450 HP w/1250 ft. lbs. Torque
  • Engine Braking: Jacobs Compression
  • 170 Amp Alternator
  • Allision 3000 MH 6-Speed Automatic transmission w/Electronic Shift Control
  • Engine Block Heater
  • Chassis Batteries: (2) 12V Maintenance 1900CCA

Construction

  • Powerlock System: Interlocking Floor, Walls, and Roof
  • Dryseal Edge Coating for all Sidewalls, Ceiling, and Floors
  • Vacu-Bond Aluminum-Framed Constructed Sidewalls, Ceiling, and Floors
  • Premium Gel Exterior Vetrosina Fiberglass Skin (No Wood Substrate)
  • Quiet Insulated, Ducted A/C System
  • Full Pass-Through Basement Storage w/ Composite Floor, Wall Construction, and Lighting
  • Basement Storage Lighting w/ Master Switch Inside Entry
  • Heated Fresh Water and Holding Tank Compartments (w/ Aqua Hot Operational)
  • Liberty Bridge Chassis Construction
  • Steel-Constructed Entry Step Box
  • Hydraulic and Electric Slideout Systems
  • 4-Point Fully-Automatic Hydraulic Leveling Jacks
  • Powder-Coated Steel Frame Chassis Construction
  • Rotocast-Molded, Durable, and Low Maintenance Service Compartment
  • Full-Coverage Heavy-Duty Undercoating
  • CSA Build (Optional)

Exterior

  • Aerodynamic Fiberglass Cap w/ Automotive-Style LED Headlighting
  • Rear Fiberglass Cap w/ Fiberglass Rear Engine Access, Automotive LED Lighting and Grill
  • Fiberglass Wheel Well Trims
  • Molded-Fiberglass One-Piece Cap
  • 4-Color Premier Full-Body Paint w/ Front Clear Mask
  • Roof-Mounted Electric Patio Awning w/ LED Lighting and Motion Sensor Retract
  • Slideout Awning Toppers above all Slideouts
  • Window Awning Package
  • Power Entry Door Awning w/ LED Lights
  • Entry Door w/ Screen Door, Latch, Deadbolt Lock, and Air Locks
  • Lighted Acrylic Grab Handle at Entry Door w/ Keyless Entry
  • Exterior Power Entry Step w/ Light
  • Side-Swing Aluminum Bus-Style Baggage Doors
  • Power Luggage Door Locks (Select Doors)
  • Exterior Luggage Door Handles
  • Large Dark-Tinted Frameless Windows
  • LED Patio Light
  • Front, Side, and Rear LED Clearance and Marker Lighting
  • Exterior Service Station: Water Pump Switch, Exterior Shower, Black Tank Flush, City Water Hook-Up, Towel Holder, and Drainage Valves
  • Exterior Park Cable and Satellite Hook-Up
  • Hitch: 15,000 lb. Capacity w/ 7-Way Round Tow Connection
  • Winegard 360 TV Antenna
  • Battery Disconnect
  • Rear Ladder
  • Winegard In-Motion Satellite System
  • Winegard Trav'ler DISH Network Satellite System
  • Winegard Trav'ler DIRECTV Satellite System
  • Roof Vent Rain Covers
  • 1st Bay 90" Tray Package
  • 1st Bay 36"/54" Tray Package
  • Exterior Freezer
  • Undercarriage Lighting
  • Exterior Accent Lighting Under Slideout
  • Full-Length Rear Mudguard w/ Stainless Accent
  • Emergency Exit Door

Cab Exterior

  • Automotive-Style One-Piece Windshield
  • Daytime Running Lights
  • Top Mount Power/Heated Mirrors w/ Turn Signals and Side Cameras- Chrome
  • Tinted Driver Window Power
  • Tinted Frameless Passenger Window
  • Fog Lamps
  • Top-Mounted Windshield Wiper System

Cab Interior

  • LED OptiView Instrument Panel (FCCC)
  • High-Output Dash Air Conditioning and Heat
  • Air Suspension Deflation System
  • Electronic Cruise Control
  • Windshield Wipers w/ Delay
  • Remote Switch for Power and Heated Mirrors
  • Steering Wheel w/ Tilt and Telescoping Column
  • Driver Console w/ Lower Storage Bin
  • Dash Radio: Dual 10" Touchscreen w/ Bluetooth, GPS Navigation, CD/DVD, SiriusXM Radio Capability, and Back-Up Monitor
  • SiriusXM Satellite Radio Ready (Requires Subscription)
  • JBL Premium Audio Sound System (Technology Package) (Optional)
  • Blind Spot Detection
  • USB and Auxiliary Inputs
  • Wireless Cell Phone Charging Pads at Driver and Passenger
  • Driver Chair w/ Heat and Air-Cool, Reclining Back, Swivel, 6-Way Power Controls, and Power Footrest
  • Passenger Chair w/ Heat and Air-Cool, Reclining Back, Swivel, 6-Way Power Controls, and Power Footrest
  • Integrated Driver and Passenger Seat Belts w/ Adjustable Straps
  • 12V Accessory Ports
  • 110V A/C Outlet at Dash Area
  • Automotive-Style Wrap-Around Dash
  • Passenger Armrest
  • Driver and Passenger Cup Holders
  • Front Power Roller Shade/Blind
  • Driver and Passenger Entry Door Power Shade/Blind
  • Adjustable Suspended Pedals
  • Power Stepwell Cover
  • Cab Lights
  • Generator On/Off Switch
  • Auxiliary Start Switch

Interior

  • Loveseat (Optional)
  • Sofa Sleeper w/ Full-Sized Mattress
  • Theater Seating Sofa w/ Power Footrest
  • Dual Euro Recliners w/ Table (Optional)
  • Free-Standing Dinette
  • Interior Flat Soft-Touch Vinyl Ceiling
  • Porcelain Tile Flooring
  • Full-Extension Drawer Guides Throughout w/ Latches
  • Cabinet Doors w/ Hidden Hinges
  • Hardwood Doors and Drawers
  • Color Coordinating Solid Wood Fascia
  • Solid Wood Valances w/ Fabric Wrapped Inserts
  • Power Day/Night Roller Shades
  • Energy Efficient LED 3" Puck Flush Mount Ceiling and Under Cabinet Lighting
  • Three Interior Décor Choices
  • Four Wood Color Choices

Interior Entry

  • Solid Surface Entry Step w/ LED Accent Lighting
  • Battery Disconnect and Control Panel
  • Metal Interior Grab Handle at Entry

Kitchen

  • Residential 4-Door Refrigerator w/ Ice and Water Dispenser
  • 2-Burner Recessed Induction Cooktop
  • Residential Over-the-Range Convection Microwave
  • Dishwasher (Optional)
  • Quartz Countertop
  • Tile Backsplash
  • Stainless Steel Sink w/ Colander, Cutting Board, and Drying Rack
  • Residential Faucet w/ Pull-Out Sprayer
  • Adjustable Shelves Throughout Kitchen
  • Full-Extension Drawer Guides w/ Latches
  • Fan-Tastic Power Vent w/ Wall Switch
  • Wastebasket
  • Wine Cooler

Bedroom or Bunk Area

  • King-Sized Encore Series Memory Foam Mattress w/ Adjustable Head
  • Designer Bedspread, Pillow Shams, and Pillows
  • Solid-Wood Valances w/ Fabric-Wrapped Inserts
  • Quartz Nightstand Tops
  • Safe

Bathroom

  • Quartz Bathroom Countertop
  • Tile Backsplash
  • Residential Faucet
  • Deluxe Hardwood Medicine Cabinet w/ Mirror
  • Tile Shower Enclosure
  • Glass Shower Door
  • Shower Skylight
  • Metal Shower Head w/ Sliding Adjustable Bar, Soap Dish and Matching Faucet
  • TECMA Porcelain Macerator Toilet
  • Fan-Tastic Power Vent w/ Wall Switch
  • Towel Rings

Entertainment

  • LED Smart TV (Bedroom)
  • LED Smart TV (Living Area, Televator)
  • LED Smart TV (Front Overhead) (Optional)
  • HDMI/CATS Video Distribution and Wiring
  • Camera Switching to Living/Bedroom TVS
  • Blu-Ray Player w/ WiFi
  • JBL Soundbar
  • Exterior Entertainment Center: LED Smart TV and JBL Soundbar

Electric & Utilities

  • Technology Package: WiFi Extender, Cell Booster, 300W Solar Panel, KBL Premium Audio System, WiFiRanger
  • High-Efficiency LoPro Ducted 15,000 BTU A/C Units w/ Front and Rear Heat Pump
  • Roof A/C Condensation Lines
  • Aqua Hot 450D
  • Service: 50 Amp
  • Converter: 125 Amp Power Converter
  • Inverter: Single 2800W Pure Sine
  • Neutral Loss Protection
  • Generator: 12.5kw Onan Quiet Diesel
  • Automatic Generator Start
  • 6V Auxillary AGM Batteries
  • Battery Upgrade Package: Lithium Batteries (Optional)
  • Master Battery Disconnect Switch
  • Water Filtration System (Whole Coach)
  • Macerator Holding Tank Dump System
  • UViaLite Waste Tank Purification System
  • Electric Power Cord Reel
  • Power Water Hose Reel
  • 50 Amp Shoreline Power Cord
  • Samsung 220V Stackable Washer and Dryer
  • Central Vacuum
  • Cable TV and Satellite Hook-Up
  • Toilet Tank San-T-Flush System
  • Multiplex Wiring Control System w/ Tough Screen and App Control
  • Carbon Monoxide and Smoke Detectors, Fire Extinguisher
  • Exterior GFCI Receptacle in Exterior Storage
  • 100W Solar Panel
  • 300W Solar Panel (Technology Package) (Optional)
  • Cellular Booster (Technology Package) (Optional)

See us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.

Due to Covid19 supply chain issues, some features and options shown may be temporarily substituted or removed.

Manu-Facts:

American Coach Logo

A Legacy of Luxury - 30 Years



When it comes to what makes a luxury brand—whether it’s watches, crystal, fashion or motor coaches—there are three key factors: materials, craftsmanship and legacy.



At American Coach, we only use top-of-the-line components and the latest technology and then follow rigid construction standards. That’s because we stake our reputation on both what we build with and how we build it. After all, we have a history we need to live up to—being the premier luxury motorcoach company. It’s what we’ve been for 30 years. And we intend to keep it that way.
